ETOE Firmware Upgrade

To achieve the peak performance of your ETOE projector, it is highly recommended to keep its firmware up to date all the time.

Content
1.Check the necessity of firmware upgrade
2.How to update the firmware of your ETOE projector?
3.How to check the results of the update?
4.Troubleshooting
5.Introducing our new firmware
6.Choose your model and download the firmware


Check the necessity of firmware upgrade

1. Turn on the projector and go to HomePage>Settings>About;
2. Check the version number on “System Version”;
3. If the version is not the same as the newest one, it is recommended to update to the newest one. The download address is at the end of this page.



How to update the firmware of your ETOE projector?

Preparation:

1.A USB stick with FAT32 format and its capacity should be less than 64 GB.

2.The right firmware in bin format.

Product: D2(A1171),D2 Pro(A1172), E2(A1191),E2 Pro(A1192)

1. Download the newest firmware for your projector model at the bottom of this page, choose the file type according to your situation.

  • Rar Version: The file ended with ".rar" has been compressed to a smaller size. Unzip the file. Highly recommend using "The Unarchiver" for Mac and " 7-zip" for Windows laptops.
  • Bin Version: The file ended with".bin" is the original file so that the file size will be large.

2. Copy the firmware file to the root folder ( highest folder in the hierarchy) of the USB flash;
3. Connect the USB flash to the projector on the USB port;
4. Plug in the power cord of the projector and long press the power button;
5. The update will start automatically, and the screen will showed a upgrade bar as below;

6. After the update finishes, the projector will restart automatically.

Product: D1(A1121)

1. Download the firmware;
2. Copy the software to the root file of your USB flash;
3. Power on the projector;
4. Plug in the USB flash to the USB port of the projector;
5. Select Setting>software update with USB flash;
6. Wait for the update.

Product: E3 Pro (A1332)

1. Download the newest firmware for your projector model at the bottom of this page, choose the file type according to your situation.

  • Rar Version: The file ended with ".rar" has been compressed to a smaller size. Unzip the file. Highly recommend using "The Unarchiver" for Mac and " 7-zip" for Windows laptops.
  • Bin Version: The file ended with".bin" is the original file so that the file size will be large.

2. Copy the firmware file to the root folder ( highest folder in the hierarchy) of the USB flash;
3. Connect the USB flash to the projector on the USB port;
4. Plug in the power cord of the projector and long press the power button;
5. The update will start automatically, and the screen will showed a upgrade bar as below;

6. After the update finishes, the projector will power off automatically;
7. Turn on the projector, and a page to set language will appear. Choose the language you prefer, navigate to compete button, and press "OK" to finish it.

Watch the video to understand it better

How to check the results of the update?

Product: D2,D2 Pro, E2,E2 Pro,E3 Pro

1. Go to HomePage of the projector,
2. Choose Settings>about>
3. Check the System Version to see if it is upgraded to the newest version.

Product: D1

1. Go to Setting>Version

Troubleshooting

Case  Solution
Remote or projector can't work after the upgrade.

1.Make sure to upgrade with the correct model version. If it's the wrong firmware, upgrade the correct firmware again.

2.Check the battery is good on the remote by clicking any button to see if the indicator turns on blue or red.

The upgrade process is interrupted, and the power off. Re-do the upgrade again. Plug in the USB flash, power on the projector, and long-press the power button.
Nothing happens after power is on. The USB flash with the firmware has been inserted into the projector.

For D2,D2 Pro, E2, E2 Pro:

1.The USB flash is inserted first and then connect the power cord. The indicator behind the projector turns red.

2. Make sure to long-press the button power until the upgrade bar appear.



For D1

Make sure to choose setting>Software Update(USB) on the menu.



The remote control can't select language after the upgrade.

Ensure that the remote control indicator is red to control the projector system. Please press the system switch button to turn the indicator red if the remote control is blue.

The projector turns on and off and can't be controlled.

1.Please be sure that the upgrade is completed 100%. If the upgrade process is interrupted, the projector will turn on and off by itself.

2.Check if the power button is stuck. Try to release it by pressing it left and right.





Introducing our new firmware

Collapsible content

ETOE E2 Pro

  1. Better sound EQ
  2. Able to change the default screensaver video for the projector system.

  1. Fix the “no signal” issue that appears on the Android TV interface.(No signal issue only happens on some projectors with firmware V.2.6.18.)
  2. The remote control is able to control the Android TV interface while in the IR mode, when the indicator is red.(Update for version V.2.6.18.)
  3. More options for sound & picture on the on-screen second menu:

    second-menu scren

    • The original sound will be bigger by adjusting the sound equalizer on "Personal" mode. While in the projector system, as the remote indicator turns red, long pressing the focus button focus button to get the on-screen menu:

      If you want a louder sound when watching movies, please try to get personalized EQ on the "Personal" mode.

      • 120Hz (emphasize low sounds)
      • 500Hz (emphasize low sounds)
      • 1.5KHz (bring vocals out)
      • 5KHz (bring vocals out)
      • 10KHz
    • More image adjustment on "Image Mode", when choosing "Personal"
      • Brightness
      • Saturation
      • Sharpness
      • Hue
    • If you want to adjust the on-screen menu on the Android TV system, please click here for how to do that.
  4. The Android TV button will disappear on the projector system. Click the switch button on the remote control to go to the Android TV system when needed.
  5. second-menu

ETOE E2

What's new on ETOE E2 firmware (Newest Version: V2.9.13)



1. "Sound Mode" added to the second menu so that you can get louder sound by adjusting the sound equalizer on "Personal."



Long press the Menu button to get the second menu to choose below sound mode:

  • Standard
  • Music
  • Movie
  • Personal

If you want a louder sound when watching movies, please try to get personalized EQ on the "Personal."

  • 120Hz (emphasize low sounds)
  • 500Hz (emphasize low sounds)
  • 1.5KHz (bring vocals out)
  • 5KHz (bring vocals out)
  • 10KHz



2. Turn on the bidirectional feature of Bluetooth 5.1, and make ETOE E2 a speaker by the Bluetooth connection.

-Turn on the Bluetooth of your smartphone/other devices;

-Search ETOE_ProjectorA confirmation message appears on the projector and your device at the same time;

-Click "OK" on the prompt message;

-The projector is connected successfully, and you can play music.



3. Allow the adjustment on the image:

* Brightness

* Saturation

* Sharpness

* Hue

a.Long press the Menu button on the remote control.

b.The on-screen picture mode adjustment settings will appear.




 Troubleshooting
1. If your original remote loses or broke accidentally by a puppy.

Contact ETOE support for a replacement. We will send you a new remote.



2. The upgrade fails.

Make sure that you have long pressed the power button after you plug in the USB flash.



3. Get a breaking sound when adjust the equalizer.

Just adjust the equalizer and you will get a normal sound again.



4.There is no blue upgrade bar appear after I insert the USB stick.

The format of your USB stick is FAT32 / NTFS as the projector can't read exFAT format. Click here to understand how to identify the file system.



You can also test if your USB stick can be read by the projector first without understand the format of your USB stick.



You can also re-format your USB stick if you need to do so.



Download Newest Firmware (V2.09.13)

Rar Version: Download (841MB)↓

Bin Version: Download (1.49G)↓

Firmware Upgrade Guide: PDF ↓

ETOE D2 Pro

What's new on D2 Pro newest firmware



    1. The on-screen second menu will be add on to the "projector settings" menu

Check the video below to understand more.

  1. The fan noise will be control bettere and thus lower noise sound.
  2. Can control the sound of two system at one time without swiching between two systems.



    1. More options for sound & picture on the on-screen second menu:

      second-menu scren

      • The original sound will be bigger by adjusting the sound equalizer on "Personal" mode. While in the projector system, as the remote indicator turns red, long pressing the focus button focus button to get the on-screen menu:

        If you want a louder sound when watching movies, please try to get personalized EQ on the "Personal" mode.

        • 120Hz (emphasize low sounds)
        • 500Hz (emphasize low sounds)
        • 1.5KHz (bring vocals out)
        • 5KHz (bring vocals out)
        • 10KHz
      • More image adjustment on "Image Mode", when choosing "Personal"
        • Brightness
        • Saturation
        • Sharpness
        • Hue
      • If you want to adjust the on-screen menu on the Android TV system, please click here for how to do that.
    2. The Android TV button will disappear on the projector system. Click the switch button on the remote control to go to the Android TV system when needed.

second-menu

Troubleshooting

Contact ETOE support for a replacement. We will send you a new remote.


The instruction for the new remote:

① Power button

  •  Press the button once: power on
  • Press the button twice: power off

② Mute

Mutes the projector's audio

③ OK

Press the confirm a selection or entry

④ Navigate control

Navigate menus or adjust the selected content

⑤ Return

Return to the previous Menu

⑥ Google Voice Control

Activate Google Assistant, Google's voice-powered virtual assistant service

⑦ Home

Press the button for once, go to Android TV homepage

⑧ Volume

Volume down / up

⑨ Netflix

Preset Netflix button

 Prime video

Preset Prime Video button

⑪ Menu

Press to launch the on-screen settings menu.

⑫ Switch

Press the button once, go to projector Homepage



The function of the old remote button will change. Please follow the below manual for the revised remote feature.



 Button       Icon

IR Mode

(indicator light is red)🔴

Bluetooth Mode

(indicator light is blue) 🔵

     Power Power



 N/A Activate Google assistant, Google's voice-powered virtual assistant service.

③④

     Navigate menus or select content. Navigate menus or select content.

        OK Press to confirm a selection or entry. Press to confirm a selection or entry.

Return to the previous menu. Return to the previous menu.

      Press to access the Android TV interface. Press to access the Android TV interface.

        Long-press to launch the projector's on-screen settings menu in the projector system.
Press to access Google Play for more apps.

⑪⑫

       Turn the projector system volume up/down. Turn the Android TV system volume up/down.

  N/A Preset Netflix button

   N/A Preset Prime Video button

N/A Click to switch to the projector system


🔴  / 🔵

(indicator)

Press button ⑮. When indicator turns blue, Bluetooth mode is enable. N/A



Make sure that the indicator of the remote turns red, and you will be able to control the projector. You will be on the language choosing page; please choose "complete" with the right navigator button after confirming your language.



  1. Please be sure that when you press the google assistant button, the remote indicator turns blue.
  2. If the remote indicator fails to turn blue, press the home button to switch the remote into the Bluetooth mode
  3. If the indicator turns blue and the voice control still can't work, try to change new batteries for the remote control.

Please be sure that the format of your USB stick is FAT32 and its capacity is less than 64GB. Click here to understand how to identify the file system.

You can also re-format your USB stick if you need to do so.



Firmware Download Link

Rar Version: Download(740MB)↓

Bin Version: Download(1.4G)↓

ETOE D2

What's new on ETOE D2 firmware (Newest Version: V2.9.22)

1. Fix the issue that YouTube videos might not be cast or mirrored to the projector stably. (Firmware versions that are earlier than V.2.3.28. Please notice that 3.28 is the released date of the firmware)

2. Able to set the timer for the Companion mode or turn off it. (Settings>other settings>Screen Saver>off)

3. The original sound will be bigger and "Sound Mode" added to the second menu so that you can get louder sound by adjusting the sound equalizer on "Personal."



1)Long press the Menu button to get the second menu to choose below sound mode:

  • Standard
  • Music
  • Movie
  • Personal



2)If you want a louder sound when watching movies, please try to get personalized EQ on the "Personal."

  • 120Hz (emphasize low sounds)
  • 500Hz (emphasize low sounds)
  • 1.5KHz (bring vocals out)
  • 5KHz (bring vocals out)
  • 10KHz



3)Allow the adjustment on the image. Choose Image Mode>Personal, and you can make your own settings for the image.

  • Brightness
  • Saturation
  • Sharpness
  • Hue



 Troubleshooting
1. If your original remote loses or broke accidentally by a puppy.

Contact ETOE support for a replacement. We will send you a new remote.



2.There is no blue upgrade bar appear after I insert the USB stick.

The format of your USB stick is FAT32 / NTFS as the projector can't read exFAT format. Click here to understand how to identify the file system.



You can also test if your USB stick can be read by the projector first without understand the format of your USB stick.



You can also re-format your USB stick if you need to do so.




Downloads

Newest Firmware (V2.09.22)

Rar Version: Download (831MB)↓

Bin Version: Download (1.49G) ↓

Instructions: PDF ↓



ETOE D1


What's new on ETOE D1 firmware (Newest Version: V2.0-20221013)

1. Better sound balance;
2. Control volume up / down function with the control panel on the projector;
3. Decrease the power assumption, as producing eco-friendly products is one of our mission.

Button Before  After (V2.0-20220829)
  • Press the button for once: power on
  • Press the button for twice: power off
  • Press the button for once: power on
  • Press the button for twice: power off
  • Press to confirm a selection or entry
  • When playing videos, press to pop up the video control menu
  • Press to confirm a selection or entry
  • When playing videos, press to pop up the video control menu
  • Navigate menus or adjust the selected content

  • Volume up /down
  • Navigate menus or adjust the selected content after pressing OK button
  • Return to the previous menu
  • Return to the previous menu



Check the necessity of firmware upgrade

1. Turn on the projector and go to HomePage>Settings>Version;
2. Check the version number, and version number is generally named after the created date;
3. If the version is not the same as the newest one, it is recommended to update to the newest one.

How to upgrade the firmware?

1. Download the firmware;
2. Copy the software to the root file of your USB flash;
3. Power on the projector;
4. Plug in the USB flash to the USB port of the projector;
5. Select Setting>software update with USB flash;
6. Wait for the update.


Troubleshooting
1. If your original remote loses or broke accidentally by a puppy.

Contact ETOE support for a replacement. We will send you a new remote.



2.There is no blue upgrade bar appear after I insert the USB stick.

The format of your USB stick is FAT32. Click here to understand how to identify the file system.



You can also test if your USB stick can be read by the projector first without understand the format of your USB stick.



You can also re-format your USB stick if you need to do so.

Newest Firmware (V2.0-20221013)

Bin Version: Download (2.79MB)

ETOE E3 Pro

Subscribe to us

Be the first to hear about new firmware upgrade of your purchase and giveaways of new release.

Subscribe

Need more help?

Special Offer

ETOE provides an extended 6-month warranty to the automatic 12-month warranty for registered customers.

Click for the registration
